SpaGER: Quick Start Guide

Introduction

SpaGER (Spatial Gene Expression in R) is a high-performance R implementation of the SpaGE algorithm for predicting genome-wide expression profiles in spatial transcriptomics data through integration with scRNA-seq reference datasets.

Why SpaGER?

Spatial transcriptomics technologies provide invaluable spatial context but often measure only a limited panel of genes. SpaGER addresses this limitation by:

Leveraging scRNA-seq data to impute unmeasured genes in spatial data
Using domain adaptation via Principal Vectors (PVs)
Providing C++ acceleration for high performance
Supporting seamless Seurat integration

Installation

# From R-Universe (recommended)
install.packages("SpaGER", repos = "https://zaoqu-liu.r-universe.dev")

# From GitHub
remotes::install_github("Zaoqu-Liu/SpaGER")

Basic Usage

Load Package

library(SpaGER)

Generate Simulated Data

For demonstration, we create simulated spatial and scRNA-seq datasets:

set.seed(42)

# Simulate scRNA-seq reference data
n_rna_cells <- 500
n_spatial_cells <- 200
n_shared_genes <- 100
n_rna_only_genes <- 50

# scRNA-seq data: cells x genes
rna_data <- matrix(
  abs(rnorm(n_rna_cells * (n_shared_genes + n_rna_only_genes), mean = 5, sd = 2)),
  nrow = n_rna_cells
)
colnames(rna_data) <- c(
  paste0("SharedGene", 1:n_shared_genes),
  paste0("RNAOnlyGene", 1:n_rna_only_genes)
)
rownames(rna_data) <- paste0("RNACell", 1:n_rna_cells)

# Spatial data: only shared genes
spatial_data <- matrix(
  abs(rnorm(n_spatial_cells * n_shared_genes, mean = 5, sd = 2)),
  nrow = n_spatial_cells
)
colnames(spatial_data) <- paste0("SharedGene", 1:n_shared_genes)
rownames(spatial_data) <- paste0("SpatialSpot", 1:n_spatial_cells)

cat("scRNA-seq data:", nrow(rna_data), "cells x", ncol(rna_data), "genes\n")
#> scRNA-seq data: 500 cells x 150 genes
cat("Spatial data:", nrow(spatial_data), "cells x", ncol(spatial_data), "genes\n")
#> Spatial data: 200 cells x 100 genes

Run SpaGE Prediction

# Predict unmeasured genes
predicted <- SpaGE(
  spatial_data = as.data.frame(spatial_data),
  rna_data = as.data.frame(rna_data),
  n_pv = 30,                # Number of principal vectors
  n_neighbors = 50,         # k for KNN imputation
  verbose = TRUE
)

# Check results
cat("\nPredicted:", ncol(predicted), "genes for", nrow(predicted), "spatial spots\n")
#>
#> Predicted: 50 genes for 200 spatial spots
head(predicted[, 1:5])
#>              RNAOnlyGene1 RNAOnlyGene2 RNAOnlyGene3 RNAOnlyGene4 RNAOnlyGene5
#> SpatialSpot1     5.052071     4.473041     5.137224     4.748652     4.786710
#> SpatialSpot2     5.204982     5.343771     5.186167     4.870106     5.362815
#> SpatialSpot3     5.500350     5.128955     4.858680     4.870086     4.983224
#> SpatialSpot4     4.914745     5.253821     4.816689     5.028372     4.672101
#> SpatialSpot5     5.061131     5.269184     4.849490     5.045723     4.868479
#> SpatialSpot6     4.912111     5.250018     5.033773     5.171062     5.024322

Predict Specific Genes

# Predict only specific genes of interest
genes_of_interest <- c("RNAOnlyGene1", "RNAOnlyGene10", "RNAOnlyGene25")

predicted_specific <- SpaGE(
  spatial_data = as.data.frame(spatial_data),
  rna_data = as.data.frame(rna_data),
  n_pv = 30,
  genes_to_predict = genes_of_interest,
  verbose = FALSE
)

cat("Predicted genes:", colnames(predicted_specific), "\n")
#> Predicted genes: RNAOnlyGene1 RNAOnlyGene10 RNAOnlyGene25

Cross-Validation

Evaluate prediction accuracy using leave-one-gene-out cross-validation:

# Run CV on a subset of shared genes
cv_genes <- paste0("SharedGene", 1:10)

cv_results <- SpaGE_cv(
  spatial_data = as.data.frame(spatial_data),
  rna_data = as.data.frame(rna_data[, c(paste0("SharedGene", 1:n_shared_genes))]),
  n_pv = 20,
  genes = cv_genes,
  verbose = FALSE
)

# Summary
cat("Cross-validation Results:\n")
#> Cross-validation Results:
cat("Mean Spearman correlation:", round(mean(cv_results$correlation), 3), "\n")
#> Mean Spearman correlation: 0.007
cat("Median Spearman correlation:", round(median(cv_results$correlation), 3), "\n")
#> Median Spearman correlation: 0.022

Visualize CV Results

# Plot correlation distribution
hist(cv_results$correlation,
     breaks = 20,
     main = "Leave-One-Out Cross-Validation",
     xlab = "Spearman Correlation",
     col = "#3498db",
     border = "white")
abline(v = mean(cv_results$correlation), col = "red", lwd = 2, lty = 2)
legend("topright", legend = paste("Mean =", round(mean(cv_results$correlation), 3)),
       col = "red", lty = 2, lwd = 2)

Accessing Metadata

SpaGE returns additional metadata as attributes:

# Access metadata from prediction result
cat("Number of PVs requested:", attr(predicted, "n_pv"), "\n")
#> Number of PVs requested: 30
cat("Number of PVs used:", attr(predicted, "n_pv_used"), "\n")
#> Number of PVs used: 21
cat("Number of shared genes:", attr(predicted, "n_shared_genes"), "\n")
#> Number of shared genes: 100
cat("Top PV similarities:", round(head(attr(predicted, "similarities"), 5), 3), "\n")
#> Top PV similarities: 0.893 0.86 0.838 0.823 0.798

Session Information

sessionInfo()
#> R version 4.4.0 (2024-04-24)
#> Platform: aarch64-apple-darwin20
#> Running under: macOS 15.6.1
#>
#> Matrix products: default
#> BLAS:   /Library/Frameworks/R.framework/Versions/4.4-arm64/Resources/lib/libRblas.0.dylib
#> LAPACK: /Library/Frameworks/R.framework/Versions/4.4-arm64/Resources/lib/libRlapack.dylib;  LAPACK version 3.12.0
#>
#> locale:
#> [1] C
#>
#> time zone: Asia/Shanghai
#> tzcode source: internal
#>
#> attached base packages:
#> [1] stats     graphics  grDevices utils     datasets  methods   base
#>
#> other attached packages:
#> [1] SpaGER_1.0.0
#>
#> loaded via a namespace (and not attached):
#>  [1] cli_3.6.5           knitr_1.51          rlang_1.1.7
#>  [4] xfun_0.56           otel_0.2.0          textshaping_1.0.4
#>  [7] jsonlite_2.0.0      future.apply_1.20.1 listenv_0.10.0
#> [10] htmltools_0.5.9     ragg_1.5.0          sass_0.4.10
#> [13] rmarkdown_2.30      grid_4.4.0          evaluate_1.0.5
#> [16] jquerylib_0.1.4     fastmap_1.2.0       yaml_2.3.12
#> [19] lifecycle_1.0.5     FNN_1.1.4.1         compiler_4.4.0
#> [22] codetools_0.2-20    irlba_2.3.5.1       fs_1.6.6
#> [25] Rcpp_1.1.1          htmlwidgets_1.6.4   future_1.69.0
#> [28] lattice_0.22-7      systemfonts_1.3.1   digest_0.6.39
#> [31] R6_2.6.1            parallelly_1.46.1   parallel_4.4.0
#> [34] bslib_0.9.0         Matrix_1.7-4        tools_4.4.0
#> [37] globals_0.18.0      pkgdown_2.1.3       cachem_1.1.0
#> [40] desc_1.4.3
