Quick Start Guide

Introduction

scPAS (Single-Cell Phenotype-Associated Subpopulation identifier) is a computational tool designed to identify cell subpopulations associated with phenotypes by integrating single-cell RNA-seq data with bulk transcriptomics data.

Key Features

Multi-modal Integration: Combines single-cell and bulk RNA-seq data
Multiple Phenotype Types: Supports continuous, binary, and survival phenotypes
Network Regularization: Leverages gene-gene similarity networks
Statistical Rigor: Permutation-based significance testing with FDR correction

Package Installation

# Install from GitHub
if (!require("devtools")) install.packages("devtools")
devtools::install_github("Zaoqu-Liu/scPAS")

# Install dependencies if needed
if (!require("BiocManager")) install.packages("BiocManager")
BiocManager::install("preprocessCore")

Quick Example

Load Required Packages

library(scPAS)
library(Matrix)
library(Seurat)

Simulate Example Data

For this quick start, we’ll create simulated data to demonstrate the workflow:

set.seed(42)

# Simulate bulk RNA-seq data (500 genes x 50 samples)
n_genes <- 500
n_bulk_samples <- 50
n_cells <- 200

bulk_data <- matrix(
  rpois(n_genes * n_bulk_samples, lambda = 100),
  nrow = n_genes,
  ncol = n_bulk_samples
)
rownames(bulk_data) <- paste0("Gene", 1:n_genes)
colnames(bulk_data) <- paste0("Sample", 1:n_bulk_samples)

# Add log transformation
bulk_data <- log2(bulk_data + 1)

# Simulate single-cell data (same genes x 200 cells)
sc_counts <- matrix(
  rpois(n_genes * n_cells, lambda = 5),
  nrow = n_genes,
  ncol = n_cells
)
rownames(sc_counts) <- paste0("Gene", 1:n_genes)
colnames(sc_counts) <- paste0("Cell", 1:n_cells)

# Create Seurat object
sc_obj <- CreateSeuratObject(
  counts = sc_counts,
  project = "QuickStart"
)

# Add cell type labels
sc_obj$celltype <- sample(
  c("TypeA", "TypeB", "TypeC"),
  n_cells,
  replace = TRUE
)

# Simulate phenotype (continuous)
phenotype <- rnorm(n_bulk_samples, mean = 50, sd = 10)
names(phenotype) <- colnames(bulk_data)

Preprocess Single-Cell Data

Use the built-in run_Seurat() function for standard preprocessing:

# Standard Seurat preprocessing
sc_obj <- run_Seurat(sc_obj, verbose = FALSE)

# Check the result
sc_obj
#> An object of class Seurat
#> 500 features across 200 samples within 1 assay
#> Active assay: RNA (500 features, 500 variable features)
#>  3 dimensional reductions calculated: pca, tsne, umap

Run scPAS Analysis

# Run scPAS with Gaussian family (continuous phenotype)
result <- scPAS(
  bulk_dataset = bulk_data,
  sc_dataset = sc_obj,
  phenotype = phenotype,
  family = "gaussian",
  nfeature = 200,           # Use top 200 variable genes
  permutation_times = 100,  # Reduced for demo (use 1000+ in practice)
  do_imputation = FALSE,    # Skip imputation for speed
  n_cores = 1               # Single core
)

Examine Results

# View added metadata columns
head(result@meta.data[, c("scPAS_RS", "scPAS_NRS", "scPAS_Pvalue", "scPAS_FDR", "scPAS")])
#>       scPAS_RS scPAS_NRS scPAS_Pvalue scPAS_FDR scPAS
#> Cell1        0         0            1         1     0
#> Cell2        0         0            1         1     0
#> Cell3        0         0            1         1     0
#> Cell4        0         0            1         1     0
#> Cell5        0         0            1         1     0
#> Cell6        0         0            1         1     0

# Summary of cell classifications
table(result$scPAS)
#>
#>   0
#> 200

# Check significance
cat("Cells with FDR < 0.05:", sum(result$scPAS_FDR < 0.05, na.rm = TRUE), "\n")
#> Cells with FDR < 0.05: 0
cat("scPAS+ cells:", sum(result$scPAS == "scPAS+", na.rm = TRUE), "\n")
#> scPAS+ cells: 0
cat("scPAS- cells:", sum(result$scPAS == "scPAS-", na.rm = TRUE), "\n")
#> scPAS- cells: 0

Basic Visualization

library(ggplot2)

# UMAP plot colored by cell type
p1 <- DimPlot(result, group.by = "celltype", label = TRUE) +
  ggtitle("Cell Types") +
  theme(legend.position = "bottom")

# UMAP plot colored by risk score
p2 <- FeaturePlot(result, features = "scPAS_NRS") +
  scale_color_gradient2(low = "blue", mid = "white", high = "red", midpoint = 0) +
  ggtitle("Normalized Risk Score")

# Combine plots
p1 | p2

Output Structure

The scPAS function adds the following columns to the Seurat object’s metadata:

Column	Description
`scPAS_RS`	Raw risk score
`scPAS_NRS`	Normalized risk score (Z-statistic)
`scPAS_Pvalue`	P-value from permutation test
`scPAS_FDR`	FDR-adjusted p-value
`scPAS`	Classification: “scPAS+”, “scPAS-”, or “0”

Three Phenotype Types

1. Continuous Phenotype (Gaussian)

For continuous outcomes like age, BMI, gene expression levels:

result <- scPAS(
  bulk_dataset = bulk_data,
  sc_dataset = sc_obj,
  phenotype = continuous_values,
  family = "gaussian"
)

2. Binary Phenotype (Binomial)

For case-control, responder/non-responder comparisons:

# Binary phenotype (0/1)
binary_phenotype <- c(0, 1, 0, 1, 1, ...)

result <- scPAS(
  bulk_dataset = bulk_data,
  sc_dataset = sc_obj,
  phenotype = binary_phenotype,
  family = "binomial",
  tag = c("Control", "Case")  # Labels for 0 and 1
)

3. Survival Phenotype (Cox)

For time-to-event data:

# Create survival object
library(survival)
surv_phenotype <- Surv(time = survival_times, event = event_status)

result <- scPAS(
  bulk_dataset = bulk_data,
  sc_dataset = sc_obj,
  phenotype = surv_phenotype,
  family = "cox"
)

Next Steps

Algorithm Details: See vignette("algorithm") for methodology
Visualization: See vignette("visualization") for advanced plots
Case Studies: See vignette("case-survival") for real-world examples
Full Tutorial: See vignette("scPAS_Tutorial") for comprehensive guide

Session Information

sessionInfo()
#> R version 4.4.0 (2024-04-24)
#> Platform: aarch64-apple-darwin20
#> Running under: macOS 15.6.1
#>
#> Matrix products: default
#> BLAS:   /Library/Frameworks/R.framework/Versions/4.4-arm64/Resources/lib/libRblas.0.dylib
#> LAPACK: /Library/Frameworks/R.framework/Versions/4.4-arm64/Resources/lib/libRlapack.dylib;  LAPACK version 3.12.0
#>
#> locale:
#> [1] C
#>
#> time zone: Asia/Shanghai
#> tzcode source: internal
#>
#> attached base packages:
#> [1] stats     graphics  grDevices utils     datasets  methods   base
#>
#> other attached packages:
#> [1] ggplot2_4.0.1      future_1.69.0      SeuratObject_4.1.4 Seurat_4.4.0
#> [5] Matrix_1.7-4       scPAS_1.0.3
#>
#> loaded via a namespace (and not attached):
#>   [1] deldir_2.0-4           pbapply_1.7-4          gridExtra_2.3
#>   [4] rlang_1.1.7            magrittr_2.0.4         RcppAnnoy_0.0.23
#>   [7] otel_0.2.0             spatstat.geom_3.6-1    matrixStats_1.5.0
#>  [10] ggridges_0.5.7         compiler_4.4.0         png_0.1-8
#>  [13] systemfonts_1.3.1      vctrs_0.7.0            reshape2_1.4.5
#>  [16] stringr_1.6.0          pkgconfig_2.0.3        fastmap_1.2.0
#>  [19] labeling_0.4.3         promises_1.5.0         rmarkdown_2.30
#>  [22] preprocessCore_1.68.0  ragg_1.5.0             purrr_1.2.1
#>  [25] xfun_0.56              cachem_1.1.0           jsonlite_2.0.0
#>  [28] goftest_1.2-3          later_1.4.5            spatstat.utils_3.2-1
#>  [31] irlba_2.3.5.1          parallel_4.4.0         cluster_2.1.8.1
#>  [34] R6_2.6.1               ica_1.0-3              spatstat.data_3.1-9
#>  [37] bslib_0.9.0            stringi_1.8.7          RColorBrewer_1.1-3
#>  [40] reticulate_1.44.1      spatstat.univar_3.1-6  parallelly_1.46.1
#>  [43] lmtest_0.9-40          jquerylib_0.1.4        scattermore_1.2
#>  [46] Rcpp_1.1.1             knitr_1.51             tensor_1.5.1
#>  [49] future.apply_1.20.1    zoo_1.8-15             sctransform_0.4.3
#>  [52] httpuv_1.6.16          splines_4.4.0          igraph_2.2.1
#>  [55] tidyselect_1.2.1       abind_1.4-8            dichromat_2.0-0.1
#>  [58] yaml_2.3.12            spatstat.random_3.4-3  spatstat.explore_3.6-0
#>  [61] codetools_0.2-20       miniUI_0.1.2           listenv_0.10.0
#>  [64] plyr_1.8.9             lattice_0.22-7         tibble_3.3.1
#>  [67] withr_3.0.2            shiny_1.12.1           S7_0.2.1
#>  [70] ROCR_1.0-11            evaluate_1.0.5         Rtsne_0.17
#>  [73] desc_1.4.3             survival_3.8-3         polyclip_1.10-7
#>  [76] fitdistrplus_1.2-4     pillar_1.11.1          KernSmooth_2.23-26
#>  [79] plotly_4.11.0          generics_0.1.4         sp_2.2-0
#>  [82] scales_1.4.0           globals_0.18.0         xtable_1.8-4
#>  [85] glue_1.8.0             lazyeval_0.2.2         tools_4.4.0
#>  [88] data.table_1.18.0      RSpectra_0.16-2        RANN_2.6.2
#>  [91] fs_1.6.6               leiden_0.4.3.1         cowplot_1.2.0
#>  [94] grid_4.4.0             tidyr_1.3.2            nlme_3.1-168
#>  [97] patchwork_1.3.2        cli_3.6.5              spatstat.sparse_3.1-0
#> [100] textshaping_1.0.4      viridisLite_0.4.2      dplyr_1.1.4
#> [103] uwot_0.2.4             gtable_0.3.6           sass_0.4.10
#> [106] digest_0.6.39          progressr_0.18.0       ggrepel_0.9.6
#> [109] htmlwidgets_1.6.4      farver_2.1.2           htmltools_0.5.9
#> [112] pkgdown_2.1.3          lifecycle_1.0.5        httr_1.4.7
#> [115] mime_0.13              MASS_7.3-65

Zaoqu Liu

Aimin Xie

2026-01-23
