Quick Start Guide

Introduction

CellProgramMapper maps single-cell RNA sequencing data to reference gene expression programs (GEPs) using non-negative matrix factorization. This guide demonstrates the essential workflow in 5 minutes.

Installation

# From R-universe (recommended)
install.packages("CellProgramMapper",
                 repos = "https://zaoqu-liu.r-universe.dev")

# Or from GitHub
devtools::install_github("Zaoqu-Liu/CellProgramMapper")

Quick Example

library(CellProgramMapper)

# Map a Seurat object to T-cell reference
result <- CellProgramMapper(
  query = seurat_obj,
  reference = "TCAT.V1"
)

# View results
print(result)

# Get usage matrix
usage <- get_usage(result, normalized = TRUE)

# Add to Seurat object
seurat_obj <- add_results_to_seurat(seurat_obj, result)

Available References

library(CellProgramMapper)
#> CellProgramMapper v1.0.0
#> Map single cells to reference gene expression programs
#> GitHub: https://github.com/Zaoqu-Liu/CellProgramMapper

refs <- available_references()
print(refs[, c("Name", "Cell_Type", "Species")])
#>                         Name Cell_Type      Species
#> 1                    TCAT.V1   T-cells Homo sapiens
#> 2          MYELOID.GLIOMA.V1   Myeloid Homo sapiens
#> 3 BONEMARROW.CD34POS.HSPC.V1       HSC Homo sapiens

Input Formats

CellProgramMapper accepts multiple input types:

# 1. Seurat object (V4 or V5)
result <- CellProgramMapper(query = seurat_obj, reference = "TCAT.V1")

# 2. Matrix (cells × genes)
result <- CellProgramMapper(query = counts_matrix, reference = "TCAT.V1")

# 3. File path (h5ad, mtx)
result <- CellProgramMapper(query = "data.h5ad", reference = "TCAT.V1")

Working with Results

Access Usage Matrix

# Normalized (rows sum to 1)
usage_norm <- get_usage(result, normalized = TRUE)

# Raw
usage_raw <- get_usage(result, normalized = FALSE)

Access Scores

# Get computed scores
scores <- get_scores(result)

Save Results

save_results(result, output_dir = "./output", prefix = "my_analysis")

Demonstration with Simulated Data

set.seed(42)

# Simulate reference (5 programs × 100 genes)
H <- matrix(runif(5 * 100, 0, 1), nrow = 5)
colnames(H) <- paste0("Gene", 1:100)
rownames(H) <- paste0("GEP", 1:5)

# Simulate query (50 cells × 100 genes)
W_true <- matrix(runif(50 * 5, 0, 1), nrow = 50)
X <- W_true %*% H + matrix(rnorm(50 * 100, 0, 0.1), nrow = 50)
X[X < 0] <- 0
colnames(X) <- paste0("Gene", 1:100)
rownames(X) <- paste0("Cell", 1:50)

# Run CellProgramMapper
result <- CellProgramMapper(
  query = X,
  reference = H,
  verbose = FALSE
)
#> Warning: Query data does not appear to be integer counts. For best results,
#> provide raw UMI/read counts.

# Visualize
usage <- get_usage(result, normalized = TRUE)
usage_mat <- as.matrix(usage)

par(mfrow = c(1, 2), mar = c(4, 4, 2, 1))

# Heatmap
image(t(usage_mat), col = colorRampPalette(c("white", "#08306b"))(100),
      xlab = "Programs", ylab = "Cells", main = "Usage Matrix",
      axes = FALSE)
axis(1, at = seq(0, 1, length.out = 5), labels = colnames(usage_mat))

# Bar plot for first cell
barplot(as.numeric(usage[1, ]), col = "#1976d2",
        names.arg = colnames(usage),
        main = paste("Cell1 Usage"),
        xlab = "GEP", ylab = "Usage")

Simulated GEP usage visualization

Performance Tips

# For large datasets, use parallel processing
result <- CellProgramMapper(
  query = seurat_obj,
  reference = "TCAT.V1",
  n_workers = 4
)

# Data is automatically batched for memory efficiency

Next Steps

Mathematical Framework - Understand the algorithm
NNLS Solver Details - Implementation details
Visualization Guide - Create publication figures
Custom References - Build your own references
